frequency converter
static design
worldwide utility simulation
An economic solution to powering industrial equipment on all nominal utility frequencies deployed throughout the world. Utilising field-proven double-conversion technology, coupled with linear amplification, Ashley-Edison Frequency Converters provide low distortion and precise output performance.
1KVA to 800KVA
Compatible with both 50Hz & 60Hz Power Supply Network
40Hz to 500Hz Adjustable Output Frequency
Direct Digital Frequency Synthesis
frequency &
voltage conversion
Simple Installation, Plug and Play Operations
Ease of maintenance and operations, Ashley-Edison’s Frequency Converter setup is uncomplicated and simple to use.
Power Line Conditioning
Electronically delivering exceptional voltage regulation to your load.
wide range of applications
Ashley-Edison’s Frequency Converter is ideal for Marine & Shore-to-Ship Supply, Avionics, Military Diagnostic Systems, Test Laboratories, Industrial Machineries and more.
Product FINDER
SINGLE PHASE
FCSD-k
2KVA ~ 10KVA
- Input Voltage Range: 170V ~ 276V
- Output Voltage: 220V / 230V / 240V
- Output Voltage Accuracy: ±1%
- Input Frequency: 50Hz / 60Hz ±5%
- Output Frequency: 50Hz / 60Hz Selectable
FCL-H/L
1KVA ~ 20KVA
- Input Voltage: 0V ~ 300V Adjustable
- Output Voltage: 220V / 230V / 240V
- Output Voltage Accuracy: ±1%
- Input Frequency: 50Hz / 60Hz ±5%
- Output Frequency:
50Hz, 60Hz, 100Hz, 200Hz, 400Hz,
Adjustable 40~70Hz
THREE PHASE
fcm-lxt
10KVA ~ 80KVA
- Input Voltage Range: 380V / 400V / 415V ±20%
- Output Voltage: 380V / 400V / 415V
- Output Voltage Accuracy: ±1%
- Input Frequency: 45Hz ~ 65Hz
- Output Frequency: 50Hz / 60Hz Selectable
FCM-MP
10KVA ~ 800KVA
- Input Voltage Range: 380V / 400V / 415V ±20%
- Output Voltage: 380V / 400V / 415V
- Output Voltage Accuracy: ±1%
- Input Frequency: 45Hz ~ 65Hz
- Output Frequency: 50Hz / 60Hz Selectable
connect with us to discover more.
From brownouts to severe voltage fluctuations, Ashley Edison takes care of all your power needs by delivering optimised, stable voltage supply to your electrical system.
Curious to learn more? Get in touch with us. We’ll get back to you with a quote or solution within 24 hours and put all your questions to rest.
